Understanding the Blown Film Operating Line – Complete System Overview
The blown film operating line is a fully integrated production system designed to manufacture high-quality plastic films with precision, efficiency, and automation.
Each section of the line plays a vital role in maintaining film consistency, production speed, and overall product performance.
1. Raw Material Feeding & Blending
The process begins with the Gravimetric Feeding / Blending System, where raw materials such as LDPE, LLDPE, or HDPE are accurately measured and mixed.
✔ Precise material ratios
✔ Throughput control
✔ Reduced material wastage
✔ Consistent film quality
2. Extruders & Control System
The blended material enters the Extruders, where it is melted under controlled temperature and pressure.
The Extrusion Control System monitors screw speed, heat zones, and output to ensure optimal processing conditions.
- Multiple extruders combine materials for multilayer production
- Improved mechanical strength
- Enhanced film performance
- Better sealing and barrier properties
3. Multilayer Die, IBC & Auto Profile Air Ring
The molten material flows into the Multilayer Die Head, where different layers are combined to form a tubular film.
✔ Internal Bubble Cooling (IBC) for higher output
✔ Auto Profile Air Ring for uniform thickness control
✔ Improved cooling efficiency and bubble stability
4. Tower Assembly & Inflation
The molten tube exits the die and is inflated to form a bubble. The Tower Assembly stabilizes and guides the bubble as it rises.
- Adjustable height traversing oscillating haul-off
- Air board collapsor
- Air bearing cage with non-contact sensors
This section ensures thickness uniformity and balanced film stretching throughout the process.
5. Cooling System
The Air Cooling System rapidly cools the inflated bubble to stabilize film structure.
Proper cooling improves clarity, strength, and production speed while preventing deformation.
6. Collapsing & Web Handling
After cooling, the bubble is flattened using collapsing frames. The film then passes through:
- Web Guide System
- Secondary Nip with Edge Slitter
- Edge Trim Pickup
This ensures clean trimming, accurate alignment, and proper roll formation.
7. Thickness Gauge & Surface Treatment
Before winding, the film may pass through a Thickness Gauge for real-time monitoring and a Surface Treater to improve printability and adhesion performance.
8. Fully Automatic Winding System
The finished film is wound using Touch Screen Controlled Winders.
Modern systems feature fully automatic two-station surface winders that allow continuous roll changes without stopping production.
